ASTM A 387 GRADE 22

ASTM A 387 GRADE 22 Plate Specifications

Product Name ASTM A 387 GRADE 22 Plate
Category  ALLOY STEEL PLATES
Thickness 6MM-50MM
Width 1250-2500MM
Length 5000-12000MM
Technique Hot rolled, Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)





ASTM A 387 GRADE 22 PLATES, ALLOY STEEL SA 387, SA 387, ASME SA 387, ALLOY STEEL PRESSURE VESSEL PLATES, ASTM A 387 GRADE 22 GRADE 22 CL.1 SHEETS, ALLOY CHROME MOLY PLATES, ASTM A387 GRADE 2 CL.2 PLATES DEALER, ASTM A 387 GRADE 22 GRADE 22 PLATE SUPPLIER IN INDIA.

What is ASTM A 387 GRADE 22 Plate?

Dmsons Metal Pvt. Ltd. holds a prominent position as a leading wholesaler, vendor and merchant of ASTM A 387 GRADE 22 Plates. ASTM A387 Gr 22 plate is a type of steel plate that falls under the ASTM A387/ASME SA387 standard. This standard covers chromium-molybdenum alloy steel plates primarily used in pressure vessel and boiler applications at elevated temperatures. The “GRADE 22” designation specifically refers to the composition and mechanical properties of the steel plate.

The main alloying elements in ASTM A387 GRADE 22 plate are chromium and molybdenum, which enhance the plate’s resistance to high-temperature environments and provide improved mechanical properties. The addition of these elements allows the plate to maintain its strength and toughness even at elevated temperatures, making it suitable for applications in industries such as petrochemical, power generation, and refineries, where high-pressure and high-temperature conditions are common.

To ensure the quality and performance of the plate, it undergoes various tests and inspections during its manufacturing process. These tests include tensile strength tests, impact tests, hardness tests, and other mechanical and chemical analyses.

ASTM A387 GRADE 22 EQUIVALENT

BS EN ASTM/ASME UNS DIN
622-515B 10 CRMO 910 A387 / SA 387 K21590 10 CRMO 910



ASTM A387 Grade 22 Plate Chemical Composition Standard

Grade C Mn Si P S Cr Mo Ni N
Alloy Steel Gr 22 0.05 – 0.15 0.30-0.60 0.50 max 0.035 max 0.035 max 2.0 – 2.5 0.90 – 1.10

ASTM A387 Grade 22 Plate Mechanical Properties

Tensile (MPa) Yield (MPa) Elongation (50mm) Elongation (200mm) Reduction of Area
415 – 585 205 min 18% min 40% min

‎ASTM A 387 GRADE 22 Plates Price in India

If you are looking to purchase ASTM A 387 GRADE 22 Plates, it’s important to know the current market price. The ASTM A 387 GRADE 22 Plate price can vary depending on the size, thickness, and quality of the material. Dmsons offers the best price in the market and ready stock available are listed below: –

Description Price
ASTM A 387 GRADE 22 Alloy Steel Plate Rs 70,000 / Metric Ton( FOB Price)
ASTM A 387 GRADE 22 Alloy Die Tool Plate Rs 65,000 / Metric Ton( FOB Price)
High Strength Low Alloy Hot Rolled Iron Plate Rs 90,000 / Metric Ton( FOB Price)
ASTM A 387 GRADE 22 Alloy Steel Liner Plate Rs 40,000 / Metric Ton( FOB Price)
ASTM A 387 GRADE 22 Alloy Structural Plate Rs 60,000 / Metric Ton( FOB Price)
ASTM A 387 GRADE 22 Low-Alloy and High-Strength Plate Rs 85,000 / Metric Ton( FOB Price)

Please note that the prices may vary based on the quantity, location, and other factors. For accurate pricing and further details, please feel free to contact us.

ASTM A 387 GRADE 22 Plate Applications

ASTM A387 GRADE 22 plates are widely used in various applications where high-temperature resistance and pressure vessel performance are crucial. Some common applications of ASTM A387 GRADE 22 plates include:

  1. Heat Exchangers: The plates are employed in the manufacture of heat exchangers, which are essential components in various industrial processes for transferring heat between two fluids.
  2. Pressure Vessels: These plates are often used in the fabrication of pressure vessels for storage and transportation of gases and liquids in industries such as petrochemical, oil and gas, and chemical processing.
  3. Boilers: ASTM A387 GRADE 22 plates are commonly used in the construction of boilers, where they provide the required strength and resistance to high temperatures generated during the combustion process.
  4. Process Plants: Various process industries, such as chemical, pharmaceutical, and food processing, use these plates for equipment that operates under elevated temperatures and pressure conditions.
  5. Refineries: Refineries in the oil and gas industry utilize ASTM A387 GRADE 22 plates for equipment such as distillation columns and towers, where high-temperature resistance is essential.
  6. Power Generation: These plates are used in power plants for the construction of boilers, steam turbines, and other high-temperature equipment.
  7. Petrochemical Industry: ASTM A387 GRADE 22 plates find applications in the petrochemical sector for equipment that comes into contact with high-temperature and corrosive environments.

The specific application of ASTM A387 GRADE 22 plates may vary depending on the requirements of the particular industry and the intended operating conditions. These plates are favoured for their excellent high-temperature properties and resistance to corrosion, making them suitable for demanding environments in a range of industrial settings.
